Motor

PMSM (Permanent Magnet Synchronous Motor)

Power Rating

14kW, 72V

Peak Power

30kW, 360A

Rated Voltage

72V DC

Rated Speed

3000rmp

Peak Speed

5800rmp

Rating Torque

45.7Nm

Controller

App OBD

Battery Pack

120Ah 72V Lithium-ion

IP Grade

IP65

Charger

Waterproof Vehicular 25A

Charge time

4.8 hours

Dimensions

2250 x 1180 x 1270mm

Wheelbase

1500mm

Net Weight

380kg

Front & Rear Tire

25x8-12; 25x10-12

Ground Clearance

260mm

Max. Speed

High Speed: 90km/h; Low Speed: 35km/h

Distance Range

80-100km

Max. Gradeability

30〫

Max. Loading

300kg

Front Suspension

Double A-rm Independent Suspensions

Drive System

Automatic Shaft Drive

Selectable 4X2 / 4X4 / 4X4-Lock

Front Differential with Lock, Rear Differential without Lock

Rear Suspension

Double A-arm Independent Suspensions

Parking Brake

Hand-Actuated

Brake System

Four Wheels Hydraulic Disc Brakes

Loading Quantity

20FCL: 10PCS; 40’HQ : 20PCS

Colors

Black, Red, White, Yellow, Green, Orange
