PRODUCTS > UTV > 15KW ELECTRIC UTV 4X4 KXU-23

15KW ELECTRIC UTV 4X4 KXU-23

Share

split windscreen.jpg


KXU-23 Electric UTV 15kW 4x4 with 72V 160Ah LG Lithium Battery

Specifications

Vehicle Dimension: 2,850 x 1,470 x 1,800 mm

Rear Cargo Bed: 1,380 x 900 x 350 mm

Ground Clearance: 320 mm

Wheelbase: 1,900 mm

Front Tread: 1,210mm

Rear Tread: 1,220mm

Front Tyre & Rims: 25 x 8-12 inch, Alloy

Rear Tyre & Rims: 25x10-12 inch, Alloy

Front Brake System: Twin Hydraulic Disk Brakes

Rear Brake System: Twin Hydraulic Disk Brakes

Suspension: Four Wheel Independent Suspension



Motor Power: 15 KW 72V Permanent Magnet Synchronous Motor

Power Rating: 15kW

Peak Power: 30kW

Rated Voltage : 72V DC

Rated Speed: 3,000rmp

Peak Speed: 5,900rmp

Rating Torque: 108N.m

Controller: Max Input Current 450A, Max Output Current 700A, CAN2.0, Isolated IP67

Max Speed: 60km/h high speed; 30km/h low speed

Maximum Climbing: 38°

Battery: 72V 160Ah LG Lithium Battery

Battery Charging Time: 5 - 6 hours

Range for On-Road 30-40km/h: 100km +

Drive System: 4x4WD & 4X2WD switchable

Max Loading Capacity for Rear Cargo Bed: 300kgs

Seating Capacity: 240kg for 2 Person

Package: 2,320x1,470x1,240mm

N.W: 750KG

G.W: 850KG

Container Qty: 1x20'ft Container: 7pcs; 1x40'hq Container: 16pcs
